CCTV JUNCTION BOX
300.00৳
Material:Plastic
Color:White
Package Included:
1 PCS
Call For Best Price 01731605422 (WhatsApp)
Description
CCTV Junction Box is a reliable and essential accessory for protecting your security camera connections and wiring. Crafted from high-quality plastic, this weather-resistant junction box ensures durability and longevity in both indoor and outdoor environments. Its sleek design provides a professional finish, while the pre-drilled mounting holes enable quick and hassle-free installation. Ideal for housing connectors and cables, the box keeps your wiring organized and safe from environmental damage, ensuring uninterrupted surveillance performance.
Price
CCTV Junction Box Price in Bangladesh only 300 Taka
Key Features:
- Durable, high-quality plastic build camera junction box
- Weather-resistant for outdoor use
- Easy installation with pre-drilled holes
- Compact design for a neat finish
- Protects wiring and connectors from damage
- CCTV camera safety box
CCTV JUNCTION BOX Specifications |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Material | Plastic | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Dimensions | 13.4 x 13.4 x 5.6cm (WxHxD) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pipe Thread | G 3/4″ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Weather Resistance | IP66 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color | White | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Operating Temperature | -40°F – +140°F | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Humidity | 0-90% RH | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Load Bearing | 6.61 lbs | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
What is a CCTV junction box? A CCTV junction box is a protective, weatherproof enclosure used to house, organize, and protect the wiring connections (power cables, video cables, and data lines) of a security camera from environmental damage, tampering, and moisture.
Why is a junction box necessary for CCTV installations?
-
Weather Protection: Shields sensitive wire terminations and pigtails from rain, snow, dust, and UV radiation, preventing corrosion and short circuits.
-
Cable Management: Eliminates messy, exposed wiring by keeping excess cable neatly tucked inside the enclosure.
-
Security and Anti-Vandalism: Hides cable connections so intruders cannot easily cut the camera feed or tamper with the power supply.
-
Aesthetics: Provides a clean, professional finish to the installation, especially on brick or concrete walls where drilling large holes for connectors is difficult.
Where should a CCTV junction box be installed? It should be mounted directly to the wall or ceiling right behind or adjacent to the security camera, allowing the camera to mount directly onto the box’s cover plate for a seamless look.
What is the difference between an indoor and an outdoor CCTV junction box?
-
Indoor Junction Boxes: Usually made of lightweight plastic and rated for basic dust and touch protection, used in climate-controlled environments.
-
Outdoor Junction Boxes: Built from heavy-duty aluminum alloy or UV-stabilized polycarbonate with high IP ratings (IP66 or IP67) and rubber O-rings/gaskets to ensure complete waterproof and dustproof sealing.
How do you waterproof cable entry points on a junction box?
-
Use cable glands (PG connectors or waterproof joints) matched to the outer diameter of your cables.
-
Apply silicone sealant or rubber grommets around entry holes.
-
Always route the conduit or cable entries from the bottom or sides of the box rather than the top to prevent gravity from funneling rainwater inside.
What materials are commonly used for CCTV junction boxes?
-
Aluminum Alloy: Highly durable, impact-resistant, and ideal for heavy-duty outdoor commercial or industrial setups.
-
ABS Plastic / Polycarbonate: Lightweight, cost-effective, rust-proof, and excellent for standard residential installations.
Can a junction box house a power supply or balun? Yes. Larger junction boxes have enough interior space to house small 12V power adapters, miniature step-down transformers, or video baluns (for analog/HD-CCTV over twisted pair cable), keeping all active components protected close to the camera.
