Toten 22U Server Rack

Description

Toten 22U Server Rack (600×600×1200mm) is available in Bangladesh at ৳27,000 from Telecare System, the Toten importer in Dhaka. It accommodates 22 rack units of standard 19-inch equipment — switches, routers, NVRs, patch panels, and UPS units — with an 80kg load capacity, tempered glass front door with key lock, 4 pre-installed cooling fans, a 6-port PDU, and removable side panels for cable access. CE and RoHS certified. 1-year manufacturer warranty. Same-day dispatch from National Stadium Market, Dhaka. Call or WhatsApp 01731605422 for bulk/wholesale pricing.

What Is a 22U Server Rack?

A 22U server rack is a floor-standing metal enclosure that holds 22 rack units (U) of IT equipment. One rack unit equals 44.45mm (1.75 inches) of vertical mounting space. The 22U floor stand format — at 1,200mm tall — is the standard choice for small and medium-sized server rooms, network closets, and CCTV control rooms in Bangladesh. It accommodates the widest range of rack-mount equipment in the EIA-310 19-inch standard, including Cisco, MikroTik, Hikvision, Dahua, and all major networking and surveillance brands sold in the Bangladeshi market.

The Toten brand, a Chinese manufacturer specializing in server rack enclosures, is distributed in Bangladesh exclusively by Telecare System, headquartered in Motijheel, Dhaka. Toten racks carry CE and RoHS certification and are tested to IEC standards for structural integrity and EMC compliance.

Toten 22U Server Rack Full Specifications

What Equipment Fits in a Toten 22U Server Rack?

Toten 22U offers 22 rack units of usable space — enough for most small and medium network and server deployments in Bangladesh. Common configurations:

Office Network Setup (10–50 users)

• 1U: MikroTik or Cisco core switch
• 1U: TP-Link or Ruijie managed switch (access layer)
• 1U: Patch panel (24-port Cat6)
• 1U: Router / firewall appliance
• 2U: UPS (rack-mount, 1000–2000VA)
• Remaining 16U available for growth

CCTV Control Room (32–64 channels)

• 2U: Hikvision or Dahua NVR (32-channel)
• 1U: PoE switch (24-port)
• 1U: Storage expansion unit
• 2U: UPS
• Remaining 16U available for additional NVRs or VMS servers

SME Server Room

• 2U: Rack-mount server (entry-level Dell or HPE)
• 2U: Storage array
• 1U: KVM switch and console drawer
• 2U: UPS
• Remaining 15U for expansion

Toten 22U Server Rack vs 18U Server Rack: Which Do You Need?

Choose the 22U if you are deploying a rack-mount UPS alongside networking and server equipment, or if you expect to add equipment within 12 months. Choose the 18U if space is constrained and you have a stable, defined equipment list.

Installation Guide: Toten 22U Server Rack

1. Select the location. The rack requires a level, load-bearing floor surface. Minimum clearance: 600mm front and 600mm rear for airflow and cable access. Recommended ambient temperature: 18–27°C (ASHRAE A1 class).
2. Position and stabilize. Use the 4 castors to roll to final position. Engage castor brakes and lower leveling feet to stabilize.
3. Install equipment top-down. Mount heaviest equipment (UPS, servers) at the bottom to lower the center of gravity.
4. Route cables. Use included cable management brackets. Route power cables (right side) separately from data cables (left side) to reduce EMI interference.
5. Secure and lock. Lock the front door and side panels with the provided keys. Store a spare key off-site.

Frequently Asked Questions

What is the price of the Toten 22U server rack in Bangladesh? The Toten 22U Floor Stand Server Rack (600×600×1200mm) is ৳27,000 at Telecare System — the Toten importer in Bangladesh and the lowest documented market price for this model. Wholesale pricing is available for bulk orders.

What is included in the box? The package includes the rack enclosure, 4 mounting profiles (rack rails), tempered glass front door with key lock, 1 fixed shelf, 4 cooling fans, 1 six-port universal PDU, and mounting hardware with a user manual.

Is the Toten 22U compatible with Cisco, MikroTik, and Hikvision equipment? Yes. Toten 22U racks use the EIA-310 standard 19-inch mounting rails, which are universally compatible with Cisco, MikroTik, TP-Link, Hikvision, Dahua, HPE, Dell, and all major rack-mount brands sold in Bangladesh.

Does the Toten 22U come with a warranty in Bangladesh? Yes. The rack includes a 1-year manufacturer warranty covering manufacturing defects. Telecare System provides local warranty support from its service center at B.B. Stadium Super Market, Level 3, Dhaka.

What is the weight capacity? The Toten 22U supports up to 80kg — sufficient for most SME server and networking deployments including a rack-mount UPS, servers, and switching equipment.

Can I add extra cooling fans? Yes. The rack supports additional fans in the top vented panel. Adding 2 extra fans is recommended for deployments exceeding 60% rack capacity or in rooms where ambient temperature exceeds 24°C.

What is the depth of this rack? The standard model at ৳27,000 has a 600mm internal depth. An 800mm-depth variant (Toten 22U 600×800×1200mm) is available at ৳30,000 for full-depth servers requiring deeper chassis clearance.

Is delivery available outside Dhaka? Yes. Within Dhaka: 1–2 business days. Outside Dhaka: 2–3 business days. Bulk/corporate delivery is arranged separately on request.

How do I get wholesale pricing? Call or WhatsApp 01731605422 (10 AM – 8 PM). Wholesale pricing is available for IT integrators, CCTV installers, corporate buyers, and government institutions ordering 3 or more units.

Where can I see the Toten 22U in person in Dhaka? Telecare System operates a showroom at 112/B, National Stadium Market, Dhaka 1000, in the IT market near Bangabandhu National Stadium, Motijheel. Corporate office: 5th Floor, 10 Rajuk Avenue, Motijheel, Dhaka – 1000.

About Telecare System — Toten Server Rack Importer

Telecare System is a Dhaka-based telecommunications and networking equipment importer operating from Motijheel. The company is the Toten server rack importer in Bangladesh, carrying the full Toten range from 4U to 42U floor stand and wall mount enclosures. Telecare System also supplies Panasonic and TCS PABX systems, IP Phone and IP PBX Grandstream and Fanvil IP phones, Hikvision and Dahua CCTV systems, and TP-Link, Tenda, and Ruijie networking equipment.

For technical consultation, bulk orders, or corporate supply agreements: telecaresystem@gmail.com | +8801731605422 | +8801611605422.
