Merlaud MIP-CA6 IP Column Speaker | 6W

Description

Merlaud MIP-CA6 IP Column Speaker is a 6W active network speaker for announcements in reverberant halls and rooms, with built-in network audio, USB playback and an integrated amplifier. For Bangladesh installations, its 12–24VDC supply and optional PoE provide flexible power options.

Key Features of Merlaud MIP-CA6 IP Column Speaker

• 6W Nominal Power: Provides a 6W nominal power specification for network audio and announcement applications.
• High Directivity: The high-directivity speaker design is intended for use in reverberant halls and rooms.
• Rigid Aluminium Body: Features an extruded, non-vibrating rigid aluminium body with an aluminium grille.
• Tilting Bracket: Includes a tilting bracket for easier mounting and installation.
• Built-in Network Audio: The active speaker has a network audio source built in and can receive announcements from an MIP-DARS or MIP-TERS8.
• Built-in Amplifier: Includes a built-in 2×20W 8Ω amplifier and can connect one 8Ω sub speaker directly without an additional amplifier.
• USB Port: The USB port supports music playback and firmware upgrading.
• Timing Programs: Includes 4 built-in timing program schedules for automatic system control.
• Wide Power Input: Supports a 12–24VDC wide-range power supply, with PoE available as an optional feature.
• Compact Design: Product dimensions are 86 × 103 × 330 mm, with a stated pack dimension of 110 × 110 × 170 mm and pack weight of 1 kg.

Why Choose Merlaud MIP-CA6 IP Column Speaker?

Merlaud MIP-CA6 is designed for network-based announcements where controlled audio delivery is needed in halls and rooms with reverberation. Its high-directivity speaker design is intended to focus sound toward the listening area, while the built-in network audio source allows announcements through an MIP-DARS or MIP-TERS8. The 6W nominal power, 150–20,000 Hz frequency response and 88–96 dB maximum SPL specification provide a clear technical reference for system planning.

The built-in 2×20W 8Ω amplifier can connect one 8Ω sub speaker directly without an extra amplifier. USB playback and firmware upgrading provide additional practical functions. For Bangladesh installations, the 12–24VDC wide-range power input and optional PoE can be considered when selecting the available power method. The 4 built-in timing program schedules can also support automatic system control according to the configured application.

Who Should Buy Merlaud MIP-CA6 IP Column Speaker?

• System Integrators: Suitable for network audio and announcement projects requiring an active IP speaker.
• Audio Installers: Useful for installations in halls and rooms where high directivity is required.
• Commercial Projects: Suitable for projects requiring network announcements, USB playback and scheduled system control.
• Network Audio Applications: Suitable where connection with an MIP-DARS or MIP-TERS8 is required.
• Not recommended for: Applications requiring specifications that have not been provided, such as a particular outdoor rating or weatherproof certification.

Technical Specifications

Frequently Asked Questions

What is the Merlaud MIP-CA6 IP Column Speaker?

The Merlaud MIP-CA6 is a 6W active IP column speaker with built-in network audio. It is designed for announcements in reverberant halls and rooms and supports connection with an MIP-DARS or MIP-TERS8 terminal for network-based announcements.

What power supply does the Merlaud MIP-CA6 require?

The MIP-CA6 supports a wide-range 12–24VDC power supply. PoE is also available as an optional feature. The appropriate power method should be selected according to the actual installation design and the available system infrastructure.

Can the MIP-CA6 connect directly to a sub speaker?

Yes. According to the supplied specification, the MIP-CA6 has a built-in 2×20W 8Ω amplifier and can connect one 8Ω sub speaker directly without requiring an additional amplifier. The connected speaker should match the stated impedance requirement.

If your project needs a compact IP column speaker with network audio, USB playback, built-in amplification and flexible 12–24VDC power input, the Merlaud MIP-CA6 provides a specification-led option. Check your system requirements and contact us for current availability. Order Merlaud MIP-CA6 today.
